KSTAR valve regulated lead acid battery can prevent air from being absorbed into it, and at the same time it also can protect the battery from damage caused by gas emitting in the period of recharging .There is no emission of acid mist and electrolyte when the sealed battery is in floating condition. Meanwhile, the patented battery tray can match with the battery and it can protect the battery from the harm of electrolyte leakage.

General Features

● Capacity: 55-150Ah

● Features: Rack mount series, design lifetime is up to 10 years

● Application: UPS/Communication/ Electric power

Technical Specification

TYPE

Nominal

Voltage（V）

Rated Capacity（Ah)

Dimensions（mm)

Weight

Appox

（kg）

Terminal

type

20HR

10HR

5HR

1HR

Length

Width

Height

Total

Height

1.75V/C

1.8V/C

1.75V/C

1.75V/C

6-FMH-55

12

55

50

44

33

277

106

222

222

16

M1

6-FMH-75

12

75

67.5

60

45

562

114

188

188

29

M6

6-FMH-100

12

100

93

80

60

395

110

286

286

32.3

M6

6-FMH-105

12

105

95

84

63

507

110

227

227

42.7

M6

6-FMH-150

12

150

138

120

90

551

110

288

288

45.9

M6
