Aruba 7205 (RW) Controller

Model:

HPE JW735A – Aruba Controllers

Brand:

Aruba

JW735A Overview

JW735A is the network management device. The Aruba 7200 Series Mobility Controllers is the next-generation networking platform, optimized for mobile application delivery to ensure the best mobility experience over Wi-Fi.

Quick Specs

Table 1 shows the Quick Specs.

Product Code

JW735A

Form factor/footprint

1xRU

10/100/1000BASE-T?

4xCombo

1000BASE-X

4xCombo

10G Ports (10G or 1G supported)

2xSFP+

USB 2.0

2

Dimensions (H x W x D)

4.4 cm x 44.2 cm x 33.4 cm

(1.75″ x 17.38″ x 13.13″)

MTBF (Hours)

129,597 (@40C)

Product Features

? Optimized for 802.11ac, the 7200 series features a central processor with eight CPU cores to support over 32,000 devices and stateful firewall policy enforcement at 40 Gbps.

? New levels of visibility offered by AppRFTM technology allow IT to see applications by user, prioritize them, and control access based on policies.

? It also manages authentication, encryption, VPNs, IPv4/IPv6 services, the Policy Enforcement FirewallTM, Adaptive Radio ManagementTM, and RFProtectTM spectrum analysis and wireless intrusion protection.

Compare to Similar Items

Table 2 shows the comparison of 7205 Series.

Series

7205

7210

Maximum campus or remote AP licenses

256

512

Maximum concurrent users/devices

8,192

16,384

Maximum VLANs

4,096

4,096

Active firewall sessions

1 million (M)

2M

Concurrent GRE tunnels

4,096

8,192

Concurrent IPsec sessions

8,192

16,384

Concurrent SSL sessions

4,096

8,192

Firewall throughput (Gbps)

12

20

Wired Bridged Throughput (Gbps)

12

20

Encrypted throughput 3DES (Gbps)

5

7

Encrypted throughput AES-CBC-256 (Gbps)

5

7

Encrypted throughput AES-CCM (Gbps)

5

7

Encrypted throughput AES-GCM-256 (Gbps)

5

7
