Aruba IAP-314 (RW) Instant 2x/4x 11ac AP

Model:

HPE JW805A – Aruba IAP314 Access Point

Brand:

Aruba

JW805A Overview

JW805A is the Aruba Instant IAP-314 (RW) 802.11n/ac Dual 2×2:2/4×4:4 MU-MIMO Radio Antenna Connectors AP. The Aruba 310 Series access points deliver high performance and superb user experience for mobile devices, Internet of Things (IoT) devices, and applications in dense office environments. Featuring the 4×4:4SS MU-MIMO capability, advanced Aruba ClientMatch radio management, and Aruba Beacon technologies, the 310 Series enables an all-wireless digital work environment in a cost-effective manner.

Quick Spec

Table 1 shows the quick spec.

SKU

JW805A

Product Model

Aruba Instant IAP-314 (RW) 802.11n/ac Dual 2×2:2/4×4:4 MU-MIMO Radio Antenna Connectors AP

Wireless LAN Standard

IEEE 802.11ac

Frequency Band

5 GHz

2.40 GHz

Antennas

4 dual-band RP-SMA connectors for external antennas

Wireless Transmission Speed

1.69 Gbit/s

Form Factor

Wall Mountable

Ceiling Mountable

Dimension (H × W × D)

1.9″ × 7.2″ × 7.1″

Product Details

The benefits of Aruba AP-310 include:

Dual Radio 802.11ac access point with Multi-User MIMO

Built-in Bluetooth Low-Energy (BLE) radio

Advanced Cellular Coexistence (ACC)

Quality of service for unified communication apps

RF Management

Adaptive Radio Management (ARM) technology automatically assigns channel and power settings, provides airtime fairness, and ensures that APs stay clear of all sources of RF interference to deliver reliable, high-performance WLANs.

The Aruba 310 Series Access Points can be configured to provide part-time or dedicated air monitoring for spectrum analysis and wireless intrusion protection, VPN tunnels to extend remote locations to corporate resources, and wireless mesh connections where Ethernet drops are not available.

Intelligent app visibility and control

Security

Integrated wireless intrusion protection offers threat protection and mitigation, and eliminates the need for separate RF sensors and security appliances.

IP reputation and security services identify, classify, and block malicious files, URLs and IPs, providing comprehensive protection against advanced online threats.

Integrated Trusted Platform Module (TPM) for secure storage of credentials and keys.

Intelligent Power Monitoring (IPM):

Enables the AP to continuously monitor and report its actual power consumption and optionally make autonomous decisions to disable certain capabilities

For the 310 Series Access Points, the IPM power-save feature applies when the unit is powered by an 802.3af PoE source. By default, the USB interface will be the first feature to turn off if AP power consumption will exceed the available power budget. In rare cases it may be necessary to take additional power saving measures, but in most cases, the 310 Series Access Points will operate in unrestricted mode.

The Accessories

Table 2 shows the accessories of JW805A.

Mount Kit

JW046A

AP-220-MNT-W1 Basic Mount Kit:HP Aruba Campus AP Mounting Kits

JW047A

AP-220-MNT-W1W Mt Basic White Kit

Power Adaptor

R3K00A

AP-AC2-12B 12V/48W AC/DC desktop style power adapter with 2.1/5.5mm connector

External Antenna

JW009A

AP-ANT-1W 2.4-2.5GHz (4dBi)/4.9-5.875GHz (6dBi) Hi Gain Dual-band Omni-Dir Indoor Antenna

Compare to Similar Item

Table 3 shows the comparison.

SKU

JW804A

JW805A

Product Model

Aruba Instant IAP-314 (JP) 802.11n/ac Dual 2×2:2/4×4:4 MU-MIMO Radio Antenna Connectors AP

Aruba Instant IAP-314 (RW) 802.11n/ac Dual 2×2:2/4×4:4 MU-MIMO Radio Antenna Connectors AP

Wireless LAN Standard

IEEE 802.11ac

IEEE 802.11ac

Frequency Band

5 GHz

2.40 GHz

5 GHz

2.40 GHz

Antennas

4 dual-band RP-SMA connectors for external antennas

4 dual-band RP-SMA connectors for external antennas

Wireless Transmission Speed

1.69 Gbit/s

1.69 Gbit/s

Form Factor

Wall Mountable

Ceiling Mountable

Wall Mountable

Ceiling Mountable
