Scaling up is also easy. Simply add more storage, flash acceleration, and upgrade the controllers. To scale out, grow from a base of two nodes to a 12-array cluster containing up to 44PB (SAN) or 88PB (NAS) of capacity. You can cluster with DM Series all-flash models for flexible growth as your business demands.

Tech Specs

ATTRIBUTE

SPECIFICATION

DM7100H

DM7000H

DM5000H

DM3000H

NAS Scale-out

12 Arrays

Maximum Drives (HDD/SSD)

8640

5760

1728

1728

Maximum Raw Capacity

88PB*

57PB

15PB

17PB

Maximum onboard Flash Cache Based on NVMe Technology

48TB

48TB

24TB

24TB

Maximum Flash Pool

288TB

576TB

288TB

288TB

Maximum Memory

3072GB

3072GB

768GB

768GB

SAN Scale-out

6 Arrays

Maximum Drives (HDD/SSD)

4320

2880

864

864

Maximum Raw Capacity

44PB

28PB

7.5PB

8.6PB

Maximum Onboard Flash Cache Based on NVMe Technology

24TB

24TB

12TB

12TB

Maximum Flash Pool

144TB

288TB

144TB

144TB

Maximum Memory

1536GB

1536GB

384GB

384GB

Cluster Interconnect

2x 100GbE

4x 10GbE

4x 10GbE

4x 10GbE

Per High Availability Pair Specifications

Active-Active Dual Controller

Maximum Drives (HDD/SSD)

720

480

144

144

Maximum Raw Capacity

7.3PB

4.8PB

1.2PB

1.4PB

Maximum Onboard Flash Cache Based on NVMe Technology

4TB

4TB

2TB

2TB

Maximum Flash Pool

24TB

48TB

24TB

24TB

Controller Form Factor

4U

3U

2U / 24 drives

2U / 12 drives

ECC Memory

256GB

256GB

64GB

64GB

NVRAM

32GB

16GB

8GB

8GB

PCIe Expansion Slots

10

4

0

0

Onboard I/O: UTA 2 (8Gb/16Gb FC, 1GbE/10GbE, or FCVI ports MetroCluster Only

0

8

8

8

FC Target Ports (32Gb autoranging, maximum)

32

8

Not Applicable

Not Applicable

FC Target Ports (16Gb autoranging, maximum)

8

24

Not Applicable

Not Applicable

40GbE Ports (maximum)

Not Applicable

8

Not Applicable

Not Applicable

25GbE Ports

24

Not Applicable

Not Applicable

Not Applicable

10GbE Ports (maximum)

32

32

8

8

10GbE BASE-T Ports (1GbE autoranging) (maximum)

16

12

8

8

100GbE ports (40GbE autoranging)

16

Not Applicable

Not Applicable

Not Applicable

12Gb / 6Gb SAS Ports (maximum)

32

24

4

4

OS version

ONTAP 9.7 and later

ONTAP 9.4 and later

Shelves and Media

DM240S, DM120S, DM600S

Protocols Supported

FC, iSCSI, NFS, pNFS, CIFS/SMB

Host/Client Operating Systems Supported

Microsoft Windows, Linux, VMware, ESXi

DM Series Hybrid Software

The ONTAP 9 software bundle includes a set of products that delivers leading data management, storage efficiency, data protection, high performance, and advanced capabilities such as instant cloning, data replication, application-aware backup and recovery, and data retention. For more details, visit the ONTAP datasheet.
