This next-generation, high-end hybrid flash storage system is designed to provide excellent data services for critical enterprise applications, meeting data storage requirements across a wide range of scenarios.

Parameters

OceanStor 6810

Hardware Specifications

Maximum Number of Controllers

16

Maximum Cache (dual controllers, grows with the expansion of controllers)

512 GB to 16 TB

Supported Storage Protocols

FC, iSCSI, NFS, CIFS, FC-NVMe, NVMe over RoCE, FTP*, HTTP*, NDMP and S3*, NFS over RDMA

Front-End Channel Port Types

8/16/32 Gbps FC/FC-NVMe, 1/10/25/40/100 Gbps Ethernet, and 25/100Gbps NVMe over RoCE/NFS over RDMA

Back-End Channel Port Types

100 Gbps RDMA/SAS 3.0

Maximum Number of Hot-Swappable I/O Modules per Controller Enclosure

28

Maximum Number of Front-End Host Ports per Controller Enclosure

96

Hard Disk Types

NVMe SSD, SAS SSD, SAS, and NL-SAS

Software Specifications

Supported RAID Levels

RAID 5, RAID 6, RAID10*, and RAID-TP (tolerating the simultaneous failure of three disks)

Value-Added Software

SmartAcceleration, SmartVirtualization, SmartMigration, SmartQoS, SmartQuota, SmartThin, SmartMulti-tenant, SmartCompression, SmartDedupe, SmartMobility*, SmartMove

HyperSnap, HyperReplication, HyperClone, HyperMetro, HyperCDP, HyperLock, HyperEncryption, HyperDetect*，HyperLink, CloudBackup*, NFS+
