Extended-run battery systems provide flexible runtime to critical Smart-UPS applications. Includes: Installation guide

Extended-run battery systems provide flexible runtime to critical Smart-UPS applications.

Includes: Installation guide

Output

Battery Output Voltage

192 V

Batteries & Runtime

Battery type

Lead-acid battery

Included Battery Modules

4

Battery mounting

Stand alone battery stack

Expected Battery Life (years)

3 – 5

Replacement battery cartridge note

Replace all batteries in operation together (UPS internal and external batteries) all-at-once

RBC Quantity

2

Physical

Maximum Height

87MM, 8.7CM

Maximum Width

440MM, 44.0CM

Maximum Depth

620MM, 62.0CM

Net Weight

39.4KG

Shipping weight

43.5KG

Shipping Height

184MM, 18.4CM

Shipping Width

590MM, 59.0CM

Shipping Depth

790MM, 79.0CM

Color

Black

Units per Pallet

4.0

Environmental

Operating Temperature

0 – 40 °C

Operating Relative Humidity

0 – 95 %

Operating Elevation

0 – 2011.68meters

Storage Temperature

-15 – 45 °C

Storage Elevation

0 – 15240meters
