Cisco ONE Catalyst 3850 24 Port 10G Fiber Switch IP Base

Model:

C1-WSC3850-24XS-S – Cisco ONE Catalyst 3850 Series Platform

Brand:

Cisco

C1-WSC3850-24XS-S Overview

The Cisco C1-WSC3850-24XS-S is a versatile and robust 24 Port 10G Fiber Switch under the Cisco ONE Catalyst 3850 series. Designed for advanced networking needs, this switch delivers high performance and reliability with an IP Base feature set, making it an ideal choice for enterprises looking to enhance their network infrastructure with robust security and scalability.

Quick Spec

Brand

Cisco

Model

C1-WSC3850-24XS-S

Series

Cisco ONE Catalyst 3850

Number of Ports

24

Port Type

10G Fiber

Product Features

24 10G SFP+ ports for high-speed data transfer

IP Base feature set for enhanced network capabilities

Advanced security features to protect network traffic

Enhanced scalability to grow with your network demands

Support for Cisco StackPower technology for power redundancy

Product Applications

Ideal for enterprise environments requiring high-speed data transfer and reliable connectivity

Perfect for data centers needing scalable and secure network infrastructure

Suitable for businesses looking to future-proof their network with 10G fiber connectivity

Supported Options

Cisco 10G SFP+ Transceiver Module

SFP-10G-SR

Cisco 10GBASE-LR SFP Module

SFP-10G-LR

Cisco StackPower Cable

STACK-T1-50CM

Compare to Similar Items

Model

Differences

Cisco WSC3850-48XS-S

Offers 48 ports instead of 24

Cisco C1-WS3650-24TD-S

Features 24 Ethernet ports with lower speed (1G) compared to 10G Fiber ports

Cisco C1-WSC3850-24T-S

Provides 24 Ethernet ports instead of 10G SFP+ ports

C1-WSC3850-24XS-S Specification

C1-WSC3850-24XS-S Specifications

Brand

Cisco

Model

C1-WSC3850-24XS-S

Product Name

Cisco ONE Catalyst 3850 24 Port 10G Fiber Switch IP Base

Number of Ports

24

Port Type

10G Fiber

Switching Capacity

640 Gbps

Forwarding Rate

444.44 Mpps

RAM

4 GB

Flash Memory

2 GB

Max Stacking Number

9

Stack Bandwidth

480 Gbps

Layer Support

Layer 2 and Layer 3

IP Version

IPv4 and IPv6

Routing Protocols

OSPF, BGP, EIGRP, IS-IS

Power Supply

1 redundant

Power Consumption

Max 485W

Dimensions

44.5 x 44.5 x 4.45 cm

Quality of Service (QoS)

Yes

Management

Web UI, CLI, SNMP

Operating Temperature

0 to 40??C

MTBF

279,000 hours

Warranty

Limited Lifetime Warranty
