Cisco ONE Catalyst 3850 48 Port 10G Fiber Switch IP Base

Model:

C1-WSC3850-48XS-S – Cisco ONE Catalyst 3850 Series Platform

Brand:

Cisco

C1-WSC3850-48XS-S Overview

The Cisco C1-WSC3850-48XS-S is a high-performance switch designed to meet the dynamic networking needs of modern enterprises. This Cisco ONE Catalyst 3850 model provides 48 ports of 10G fiber and operates on an IP Base license, ensuring advanced network management, security, and scalability. Ideal for enterprise campus and branch networking, it offers robust performance and support for current and future network growth.

Quick Spec

Brand

Cisco

Model

C1-WSC3850-48XS-S

Product Series

Cisco ONE Catalyst 3850

Ports

48 x 10G Fiber

License

IP Base

Product Features

48 10-Gigabit Ethernet SFP+ ports for extensive network connectivity

Offers Cisco StackWise-480 technology for stacking up to 9 switches

Supports Cisco IOS XE Software with comprehensive networking capabilities

Integrated wireless controller capability with up to 2000 access points and 20,000 clients

Advanced Layer 3 features including OSPF, EIGRP, ISIS, and BGP

Product Applications

Enterprise Campus Networks: Ideal for creating a resilient and scalable network infrastructure across large campuses.

Branch Office Connectivity: Perfect for providing reliable and high-speed connectivity across multiple branch locations.

Data Center Aggregation: Suitable for aggregating traffic at the network core and optimizing data center operations.

Supported Options

Accessory

Model

Power Supply

PWR-C1-715WAC

Fan Module

C3KX-FAN-23CFM

Network Module

C3850-NM-4-1GE

Compare to Similar Items

Feature

C1-WSC3850-48XS-S

WS-C3850-48XS-E

WS-C3850-48T-S

Ports

48 x 10G Fiber

48 x 10G Fiber

48 x 1G Copper

License

IP Base

IP Services

IP Base

Stacking

Yes (up to 9 switches)

Yes (up to 9 switches)

Yes (up to 9 switches)

Advanced Layer 3 Features

Yes

Yes

No

Wireless Controller

Yes

Yes

No

C1-WSC3850-48XS-S Specification

C1-WSC3850-48XS-S Specifications

Brand

Cisco

Model Name

C1-WSC3850-48XS-S

Product Type

Cisco ONE Catalyst 3850

Port Count

48

Port Type

10G Fiber

IP Base

Yes

Layer Support

Layer 3

Max Switching Capacity

1760 Gbps

Forwarding Rate

947.62 Mpps

StackWise-480 Stacking Support

Yes

Max Stacking

9 switches

Dimensions

1.73″ x 17.5″ x 21.5″

Power Supply

AC

Total PoE Budget

0W

MAC Address Table

32K entries

DRAM

8 GB

Flash Memory

4 GB

Operating Temperature

32?? to 104??F (0?? to 40??C)

Storage Temperature

-40?? to 158??F (-40?? to 70??C)

MTBF

315,240 hours

Management Interface

RJ-45
