Intel® Xeon® E5-2630 v4, 16GB Memory, 1TB Hard Drive and a 3 Year Warranty

Dell PowerEdge R430 Xeon E5-2630 v4 16GB 1TB SAS Rack Server Specification

Product Series

Dell PowerEdge R430 Server

Model

Dell PowerEdge R430 Xeon E5-2630 v4 16GB 1TB SAS Rack Server

Customizable

Intel® Xeon® E5-2630 v4, Windows Server® 2016 Standard, 16GB Memory, 1TB SAS Hard Drive and a 3 Year Warranty

Processor

Intel® Xeon® E5-2630 v4 2.2GHz,25M Cache,8.0 GT/s QPI,Turbo,HT,10C/20T (85W) Max Mem 2133MHz

Operating System

Windows Server® 2016,Standard,16CORE,Factory Inst,No MED,NO CAL

Memory

16GB RDIMM, 2400MT/s, Dual Rank, x8 Data Width

Hard Drive

1TB Hard Drive

Warranty

3 Year Basic Hardware Warranty Repair, 5X10 HW-Only, 5×10 NBD On-site

Chipset

Intel® C610 series chipset

Storage

SAS, SATA, Nearlline SAS, SSD

Drive Bays

Multiple R430 chassis available:

10 x 2.5″ hot-plug drives

8 x 2.5” hot-plug drives

4 x 3.5” hot-plug drives

4 x 3.5” cabled drives

Slots

2 PCIe 3.0

RAID Controllers

Internal:

PERC S130

PERC H330

PERC H730

PERC H730P

External:

PERC H830

Network Controller

4 x 1GbE LOM

Communications

Optional add-in NICs, HBAs

Power

450W, 550W PSU

Availability

ECC memory

Single Device Data Correction (SDDC)

Spare Rank

Hot-plug hard drives

Hot-plug redundant power

iDRAC8 with Lifecycle Controller

Support for HA clustering

Virtualization-ready

Internal Dual SD Module (Failsafe Hypervisor)

TPM 1.2

Graphics Card

Video Type: Integrated Matrox G200 with iDRAC8

Video Memory: 16MB shared with iDRAC8 application memory

Chassis

1U Rack

Management

Systems management:

IPMI 2.0 compliant

Dell OpenManage Essentials

Dell OpenManage Mobile

Dell OpenManage Power CenterRemote management:

iDRAC8 with Lifecycle Controller

iDRAC8 Express (default)

iDRAC8 Enterprise (upgrade) 8GB vFlash media (upgrade)

16GB vFlash media (upgrade) iDRAC Quick Sync

Dell OpenManage Integrations:

Dell OpenManage Integration Suite for Microsoft® System Center

Dell OpenManage Integration for VMware® vCenter™

Dell OpenManage Connections:

HP Operations Manager

IBM Tivoli® Netcool® and CA Network and Systems Management

Dell OpenManage
