Dual Intel® Xeon® E5-4620 v4, Optional Operating System, 32GB Memory, 300GB SAS H330 Hard Drive and a 3 Year Warranty

Dell PowerEdge R830 Dual Xeon E5-4620 v4*2/ 32GB 300G 2.5 SAS H330 Rack Server Specification

Product Series

Dell PowerEdge R830 Server

Model

Dell PowerEdge R830 Dual Xeon E5-4620 v4*2/ 32GB 300G 2.5 SAS H330 Rack Server

Customizable

Dual Intel® Xeon® E5-4620 v4, Optional Operating System, 32GB Memory, 300GB SAS H330 Hard Drive and a 3 Year Warranty

Processor

2x Intel® Xeon® E5-4620 v4 2.1GHz,25M Cache,8.0 GT/s QPI,Turbo,HT,10C/20T (105W) Max Mem 2133 MHz

Operating System

No Operating System

Memory

16GB RDIMM, 2400MT/s, Dual Rank, x8 Data Width

Hard Drive

300GB Hard Drive

Warranty

3 Years Basic Hardware Warranty Repair: 5×10 HW-Only, 5×10 NBD Onsite

Chipset

Intel C612

Embedded Hypervisor (Optional)

Microsoft Windows Server with Hyper-V®

Citrix® XenServer®

VMware vSphere ESXi

Storage

16 x 2.5” SATA/SAS SSD

SAS HDD (15K, 10K)

Nearline SAS HDD (7.2K)

Drive Bays

Up to 16 x 2.5”

Slots

7 PCIe slots:

2 x16 half-length, full-height

1 x8 half-length, full-height

3 x8 half-length, half-height

1 x8 half-length, full-height for the RAID controller

RAID Controllers

Internal controllers: PERC H330, PERC H730, PERC H730P

External HBAs (RAID): PERC H830

External HBAs (non-RAID): 12Gbps SAS HBA

Communications

Supported Select Network Adapters (NDC):

QLogic 5720 quad-port 1GbE Base-T (no TOE or iSCSI offload)

QLogic 57800S dual-port 10GbE Base-T with 2 x 1GbE (TOE and iSCSI offload available on 10GbE ports)

QLogic 57800S dual-port 10GbE SFP+ with 2 x 1GbE (TOE and iSCSI offload available on 10GbE ports)

Intel I350 quad-port 1GbE Base-T (no TOE or iSCSI offload)

Intel X540 dual-port 10GbE Base-T with 2 x 1GbE (FCoE capability enabled on the 10GbE ports)

Power

Platinum 750W AC, auto-ranging; Platinum 1600W AC, auto-ranging

Availability

Hot-plug hard drives, hot-plug redundant power, hot-plug redundant fans, ECC memory, internal dual SD module

Chassis

2U rack server

Management

Systems management:

IPMI 2.0 compliant

Dell OpenManage Essentials

Dell OpenManage Mobile

Dell OpenManage Power CenterRemote management:

iDRAC8 with Lifecycle Controller

iDRAC8 Express (default)

iDRAC8 Enterprise (upgrade)

8GB vFlash media (upgrade)

16GB vFlash media (upgrade)

iDRAC Quick SyncDell OpenManage Integrations:

Dell OpenManage Integration Suite for Microsoft® System Center

Dell OpenManage Integration for VMware® vCenter™Dell OpenManage Connections:

HP Operations Manager, IBM Tivoli® Netcool® and CA Network and Systems Management

Dell OpenManage Plug-in for Oracle® Database Manager

Rack Support

ReadyRails™ II sliding rails for tool-less mounting in 4-post racks with square or unthreaded round holes or tooled mounting in 4-post threaded hole racks, with support for optional tool-less cable management arm.

Dimensions

H: 14.17 in (36.0 cm)

W: 6.89 in (17.5 cm)

D: 17.12 in (43.5 cm)
