Built on the next-gen hardware platform architecture, HUAWEI IdeaHub S2 is equipped with Bring Your Own Meeting (BYOM), HD immersive meeting quality, Wi-Fi 6 for direct projection, and ultra-low writing latency, easily adapting to mainstream cloud meeting apps. It is a perfect solution for boundless collaboration and communication to fit in any room, such as regular meeting rooms, executive offices, and open office areas.

Product Name

HUAWEI IdeaHub S2

Product model

65″: IHS2-65SA

75″: IHS2-75SA

86″: IHS2-86SA

Product dimensions

(H x W x D)

65″: 947.5 mm x 1484.5 mm x 91.6 mm

75″: 1071.9 mm x 1705.7 mm x 91.8 mm

86″: 1212.0 mm x 1953.0 mm x 91.8 mm

Net weight

65″: 35.5 kg

75″: 47.0 kg

86″: 62.0 kg

Gross weight

(including the package)

65″: 43.0 kg

75″: 57.0 kg

86″: 73.5 kg

The dimensions and weight may vary with configuration, manufacturing process, and measurement method. The product height includes the camera (55 mm).

Component

Device

1

Stylus pens

2

Cable

Power cable x 1

Wall-mounted bracket

Optional (65″, 75″, and 86″)

Rolling stand

Optional (65″, 75″, and 86″)

IdeaShare Key

Optional (Type-A port)

OPS

Optional

Screen

Resolution

4K (3840 x 2160 pixels)

Backlight type

D-LED

Screen Lamination

Zero-gap bonding

Writing

Latency

16 ms

Touch sensing distance

≤ 1.5 mm

Intelligent writing recognition

Supports recognition of Chinese, English, and 11 types of graphics

Camera

Resolution

4K

Sharpness

1800 lines

Lens cap for privacy protection

√

Horizontal FoV

80°

TV distortion

＜2%

Speaker

Frequency domain

100 Hz to 20 kHz

Number of speaker units

4

Total power

40 W

Microphone

Sound pickup angle

180°

Sound pickup distance

12 m

Frequency domain

80 Hz to 20 kHz

Optimized sound pickup

Sound location, echo cancellation, and automatic gain control

Meeting

Native meeting apps

Huawei Cloud Meeting and WeLink

Dual streams (audio/video + data sharing)

1080p30fps+1080p30fps/4K8fps

BYOM

√

AI Function

Auto-Framing

√

Intelligent tracking

√

Acoustic baffle

√

DNN-based dereverberation

√

System

RAM

8 GB

Flash

64 GB

OS

HarmonyOS, Windows (OPS required)

Security

Embedded encryption chip that supports H.235, STARTTLS, TLS, SRTP encryption, Chinese cryptographic algorithms, secure boot, and TEE

Language

Simplified Chinese, English, French, Japanese, Arabic, Spanish, Russian, Portuguese, and Italian

Wireless connection

Wi-Fi module

Wi-Fi 6

Wi-Fi frequency

2.4 GHz + 5 GHz

NFC

√

Port

Video input

HDMI cable x 1

Video output

HDMI cable x 1

Audio input

3.5 mm (line-in) x 1

HD-AI x 1

Audio output

3.5 mm (line-out) x 1

Other ports

USB Type-A 3.0 x 3

USB Type-C x 1

RJ45 (10/100/1000 Mbit/s LAN) x 1
