Lenovo ThinkSystem 3.5 8TB 7.2K SAS 12Gb Hot Swap 512e HDD

Tech Specs

ATTRIBUTE

SPECIFICATION

Form Factor

5U

Dual Expansion Modules

Dual 12Gb SAS standard, with active/active failover

Supported Drives

84x hot-swap SAS 3.5-inch drives:4TB, 6TB, 8TB, or 10TB 7,200rpm NL SAS HDDs; 400GB SSDs (2.5-inch drive in 3.5-inch tray)

Storage Capacity (per enclosure)

Up to 840TB – 7,200rpm NL SAS HDDs; up to 33.6TB – SAS SSDs

Expandability (via Daisy-Chain)

Up to 4x D3284 enclosures per HBA

HBAs Supported

9380-4i4e SAS/SATA HBAs for System x; N2226 SAS/SATA HBAs for System x; ThinkServer 9300-8e PCIe 12Gb 8-Port External SAS Adapter by LSI

RAID Support

RAID-0, 1, 10, 5, 50, 6, 60 (HBA-dependent)

Power Supplies and Fans

2x 2214W (1+1) hot-swap/redundant 80 Plus Platinum power supplies; 5 hot-swap/redundant fans

Back Panel Connectors

Each expansion module (x2) includes: 4x ports: 3x 12Gbps Mini-SAS HD (SFF-8644) per ESM; 1x RJ45 Ethernet port for management

Form Factor / Dimensions / Weight

5U/Height: 219mm (9.5 in.); Width: 483mm (19 in. IEC60297 rack compliant); Depth: 933mm (36.75in.)/Weight: min. 64kg (141 lbs); max. 131kg (289 lbs)

Limited Warranty

3-year Limited Warranty, 9×5 Next Business Day Onsite (upgradeable)
