ThinkSystem DE6000F and DE4000F availability features include: Redundant components with automated failover Intuitive storage management with comprehensive tuning functions Advanced monitoring and diagnostics with proactive repair Snapshot copy creation, volume copy, and asynchronous and synchronous mirroring for data protection. Data assurance for data integrity and protection against silent data corruption

ThinkSystem DE6000F and DE4000F availability features include:

Redundant components with automated failover

Intuitive storage management with comprehensive tuning functions

Advanced monitoring and diagnostics with proactive repair

Snapshot copy creation, volume copy, and asynchronous and synchronous mirroring for data protection.

Data assurance for data integrity and protection against silent data corruption

Tech Specs

DE6000F

DE4000F

Form Factor

Base system: 2U/24

Expansion: 2U/24

Base system: 2U/24

Expansion: 2U/24

Maximum Raw Capacity

2.94PB

2.94PB

Maximum Drives

192

192

Maximum Expansion

Up to 7 DE240S expansions

Up to 7 DE240S expansions

IOPS

1,000,000 IOPS

300,000 IOPS

Sustained Throughput

Up to 21GBps

Up to 10GBps

System Memory

128GB

16GB

Base IO Port (Per System)

4 x 10Gb iSCSI (optical)

4 x 16Gb FC

4 x 10Gb iSCSI (optical)

4 x 16Gb FC

Optional IO Port (Per System)

8 x 16GB/32GB FC

8 x 10GB/25GB iSCSI optical

8 x 12GB SAS

8 x 16GB/32GB FC

8 x 10GB/25GB iSCSI optical

8 x 12GB SAS

Software features

Snapshot, Asynchronous mirroring, Synchronous mirroring, Drive Encryption

System Maximums

Hosts/partitions: 512

Volumes: 2,048

Snapshot copies: 2,048

Mirrors: 128

Hosts/partitions: 256

Volumes: 512

Snapshot copies: 512

Mirrors: 32
