Compact form factor for space-constrained environments ThinkShield lifecycle security, physical tamper protection, and key encrypted storage Full remote manageability Easy connectivity with cellular LTE and Wi-Fi Suitable for harsh environment with extended temperature range, high shock and vibration tolerance

Compact form factor for space-constrained environments

ThinkShield lifecycle security, physical tamper protection, and key encrypted storage

Full remote manageability

Easy connectivity with cellular LTE and Wi-Fi

Suitable for harsh environment with extended temperature range, high shock and vibration tolerance

ATTRIBUTE

SPECIFICATION

Form Factor

1U height, half width edge server; Height: 40mm, Width: 215mm, Depth: 376mm

Processor

1-socket Intel® Xeon® D-2100, up to 16 cores

Memory

Up to 256GB in 4x slots, using 64GB DIMMs; 2133/2400/2666MHz TruDDR4

Internal Storage Options

2x M.2 2280 SATA boot drives + 8x M.2 22110 NVMe data storage drives

2x M.2 2280 SATA boot drives + 4x M.2 22110 NVMe/SATA data storage drives

SED, high temperature, high capacity, and high endurance drive options

Optional encryption key deletion on tamper or theft detection

RAID Support

Software RAID available

Hardware RAID 0/1 for M.2 SATA Boot SSDs

Hardware RAID 0/1 for M.2 SATA Storage SSDs

Mounting Options

Single node mounting options for desktop, VESA, DIN, wall, or ceiling

Multi-node stackable bookend options

E1 Enclosure for two nodes side-by-side and 4x power supplies. Depth: 735mm, Height: 1U

E2 Short Depth Enclosure for two nodes sides by side + 4x power supplies: Depth: 440mm, Height: 2U

Locking bezels and dust filter options

Power

Dual-redundant external power supplies 100-240V AC

Single DC supply: -48VDC (-40VDC to -72VDC) @ 8.4A

Network Interface (Wired)

2x10GbE (SFP+), 2x 10/100MB/1GbE, 2x 1GbE management

2x10GbE (SFP+), 4x switch 10/100MB/1GbE, 1GbE management

2x10GbE, 2x 10/100MB/1GbE, 2x 1GbE management

Network Interfaces (Wireless)

Four wireless SMA connectors for LTE & Wi-Fi

Wi-Fi 64/128-bits encrypted WEP, WPA, WPA2, 802.11 a/b/g/n/ac

3G/4G Cellular LTE 3GPP Release 12 450Mbps DL/50Mbps UL

Accelerators and PCIe Expansion

1x PCIe 3.0 x16 75W or 4x M.2 22110

Support for 1x NVIDIA® T4 GPU for AI inference

Support for GPU, FGPA, ASIC accelerators

Support for operational technology networks

1x PCIe network card expansion

4x 1GbE RJ45 PCIe

2x 10GBASE-T PCIe

2x 10/25GbE SFP28 PCIe

I/O

Front: 1x VGA, 2x USB 3.0, 1x XClarity Controller management mini-USB

Rear: 1x RJ45 Console Serial, 2x USB 2.0

USB and Console ports can be disabled

Systems Management

Lenovo XClarity Administrator with mobile option

Environmental

Extended operating temperature of 0-55°C, up to 40G shock & 3Grms vibration, IEC 60068, NEBS 3, optional dust filter

Security

ThinkShield Key Vault secure management with motion and intrusion tamper protection

Optional Key Vault SED encrypted storage for boot and data drives

Lenovo Trusted Supplier Program, Secure boot, and Smart USB Protections, Lenovo Wi-Fi Security, Lenovo LTE Security

Optional Kensington keyed lock compatible chassis

Nationz TPM 2.0 for customers in China

Cable locking bezel

Operating Systems

Microsoft Windows Server, SLES, Ubuntu, RHEL, VMware ESXi, vSAN.

Limited Warranty

1-year, 3-year warranty extendable to 5-year, next business day 9×5; optional service upgrades
