Polycom USB camera Polycom poly studio Wide-angle/lens/4K video conferencing Face voice tracking Polycom Polycom studio

DIMENSIONS

Unit dimensions:

105 mm x 700 mm x 70 mm = 4.2” x 27.3” x 2.8” (HxWxD) without stand

156 mm x 700 mm x 70 mm = 6.2” x 27.3” x 2.8” (HxWxD) with stand

Weight:

5 lbs 2.6 oz (2342 g) without stand

6 lbs 4.7 oz (2856 g) with stand

Remote control dimensions:

183 mm x 40 mm x 19 mm = 7.2” x 1.6” x .75” (HxWxD)

APPLICATION REQUIREMENTS

Supported operating systems

Windows 7, 8.1, 10

MacOS 10.12, 10.13, 10.14

Support for standard audio and video device drivers

UAC 1.0 Audio

UVC 1.1/1.5 Video

HID 1.11

POWER REQUIREMENTS

12VDC/5A @ 100~240VAC, 50/60 Hz

PACKAGE INCLUDES

Poly Studio

Remote control with 2 AAA batteries

Power adapter

5 m USB 2.0 cable (Type-C to Type-A)

Wall mount kit

Setup sheet

OPTIONAL ACCESSORIES

Expansion microphone

Display mount

CAMERA

120-degree FOV

UHD 2160p (4K) capture resolution

Automatic people framing & speaker tracking

5x zoom / EPTZ

2 camera presets

AUDIO

Poly Acoustic Clarity technology provides full-duplex conversations, acoustic echo cancellation and background noise suppression

Poly Noise Block technology

Poly Acoustic Fence technology

Mute/unmute controls

Stereo microphones:

6-element beamforming microphone array

12 ft pickup range

120 Hz–16 kHz frequency response

Stereo speakers:

100 Hz–20 KHz frequency response

Output = 90 dB @ 0.5m

INTERFACES

1x USB 3.0 Type-C port (with 2.0 compatibility)

Power connector

Optional external microphone

3.5 mm stereo Audio In

Kensington security lock

802.11ac Wi-Fi wireless networking for manageability; IEEE 802.11a/b/g/n compatible

Bluetooth® 4.2

APPLICATION COMPATIBILITY

Compatible with any application that supports standard USB audio and video drivers, including but not limited to:

Certified for Microsoft Teams and Skype for Business

Zoom Certified

LogMeIn GoToMeeting®

BlueJeans Network

Google Hangouts™ communication platform

Amazon Chime

Cisco Webex®

Vidyo Desktop™

Polycom Real Presence Desktop

SECURITY

802.1x support

Certification management

MANAGEABILITY (VIA WI-FI)

Companion App (running on Win/Mac PC connected to device)

Real Presence Resource Manager

Device Management Service

WARRANTY INFORMATION

1-year limited hardware warranty

COUNTRY OF ORIGIN

Laos

ENVIRONMENTAL

Operating temperature: 32–104°F (0–40°C)

Relative humidity: 5–95%, noncondensing

Storage temperature: -13–160°F (-25°–70°C)
